Modo Snap Hinge

Eyewear for MODO Eyewear

Part of Modo eyewear collection uses an innovative Snap Hinge system that surpasses current common hinge constructions, which are made up of several components. The snap hinge’s main function is to easily join the front of a pair of glasses to their temples through a very simple method – click, by pressure – without the use of screws or welding, and instead by a reliable connection and smooth friction operation. Extreme simplicity, great reliability, maximum production economy, sustainability: for a clean design.

Download Press Kit № 135316

Download Press Kit № 135316 Eyewear for MODO Eyewear by MODO Eyewear to access high-res images, essential texts, translations, and exclusive interviews—all in one.

Available Now for Your Next Story

At fashion|newsroom, we understand the pressures and deadlines journalists face. That’s why we offer exclusive access to our curated press kits and high-resolution images, tailored for accredited journalists. These resources are designed to enrich your stories with depth and visual appeal, spotlighting the world's most innovative designs.

Please Note:

• Credit the work's creator and/or photographer.
• Mention fashion|newsroom as your source.
• Share your published pieces with us; we love to celebrate and promote your work on our platform and social media.

Let’s Collaborate: Your stories matter. fashion|newsroom is here to support you with quality, accessible content. Once you are accredited, reach out for the images and content you need. We will provide the specific images and content directly, along with recommendations on works to feature.

Get Accredited Easily: Quick access to our resources requires media accreditation. Apply for media accreditation to join our network and start exploring a wealth of design stories.

Modo Snap Hinge by MODO Eyewear

Download 1800 Pixels JPEG Image.

Eyewear by MODO Eyewear

Download 1800 Pixels JPEG Image.

MODO Eyewear Modo Snap Hinge

Download 1800 Pixels JPEG Image.

MODO Eyewear Eyewear

Download 1800 Pixels JPEG Image.

MODO EyewearBrand Logo

Download 1800 Pixels JPEG Image.

Modo Snap Hinge Eyewear Press Releases

Discover our press releases for Modo Snap Hinge available in the following languages: English.

Modo Snap Hinge Eyewear Media Articles

Utilize our prepared articles to feature Modo Snap Hinge, available in the languages: Korean, Japanese, Russian, Hindi, Turkish, Arabic (Standard), Chinese (Mandarin), English, Italian, German, Portuguese, Dutch, French, Indonesian and Spanish.

Unique Properties

Part of MODO eyewear collection uses an innovative "Snap Hinge" system that surpasses current common hinge constructions, which are made up of several components. The snap hinge’s main function is to easily join the front of a pair of glasses to their temples through a very simple method – click, by pressure – without the use of screws or welding, and instead by a reliable connection and smooth friction operation.

Tags

Simplicity, reliability, sustainability, clean design, hidden mechanism.

Production Technology

The innovation of the snap hinge is its few components: 1. A Beta-titanium temple with a specifically designed hook shape 2. A small metal cylinder that is inserted into the temple hook and acts as the temple’s rotation mechanism. The cylinder heads have a particular bi-conical surface that allows the ‘snap’ attachment to the frame front, for a very resilient one-time-only attachment and unlimited lifespan. 3. An ultra-performing polymer frame front made by a specialised injection molding technique that allows the creation of an internal ‘undercut’ cavity, which serves as the house for the metal cylinder.

Design Challenge

The seeming simplicity of the final result hides a constructive difficulty that we had to overcome with an advanced molding process. The most difficult part was to make the cavity / house of the cylinder inside the plastic polymer front, since it is to be made with a particular undercut that generally in injected front pieces it is not possible.

Project Duration

The project started in 2020 and launched into Spring-Summer 2022.

Operation Flow

The assembly process is extremely simple and reduced to only two operations: 1. Insertion of the metal cylinder into the Beta-titanium temple hook 2. Pressure insertion of the cylinder + temple assembly into the injected polymer front’s housing. This new construction is stable and resilient, and the bi-conical surface processing of the cylinder heads prevents the metal cylinder from rotating inside the front piece. The temple hook surrounds the cylinder and rotates around the cylindrical surface. This particular combination of metallic materials allows fluid motion and frictional rotation, thanks to the particular self-lubricating operation of the two different materials. In terms of perception and design, the hinge mechanism is completely hidden inside the end-piece of the frame front. Depending on the transparency of the chosen polymer, it is possible to decide to show the mechanism with transparent shades or to hide it completely with opaque colors. Extreme simplicity, great reliability, maximum production economy, sustainability: for a clean design.

Research

Eyewear frames generally feature hinges with several disadvantages related to the complexity of production and assembly / disassembly, as well as the actual durability of the coupling between the temple and the spectacle front piece. In particular, hinges provided with a screw pin and corresponding coupling elements, which can be fixed to the temples and front-piece require long and complex production steps. The use of screw pins and / or screw connections will eventually lead to loosening and wear in the long run, which will reduce the service life of the hinge and of the frame. With regards to the hinges that do not use a screw coupling, they are rather complex. Therefore, a large number of components and their mutual couplings are required, and with their particular shapes they necessitate high production costs. It is an object of the present invention to provide a simple screw-less hinge capable of ensuring a robust and reliable coupling between the temples and the front piece of the spectacles in order to simplify the mounting steps. Advantageously, the spectacle frame of the present invention makes it possible to: - reduce production costs compared to the existing frames; - has an high level of reliability due to the reduced number of its components; - simplify the assembly steps; In terms of design, this innovation allows the hinge to be completely hidden inside the injected front, creating a minimal and clean and eco-sustainable hidden design as the components and processes used are truly reduced. However, the extreme reduction of components required a high degree of engineering and precision, both in the realisation of the mold for the production of the front with seat obtained, of the steel cylinder, and a perfect calibration of the temple-hook in bent beta titanium. Industrialising the perfect assembly to have a lasting friction were the final steps of this project.

Inspiration

The inspiration comes from other connection systems present in nature or in mechanical and handcrafted pieces, with the difference that in this case the various materials and their natural elasticity have been exploited in a way that reduces the number of moving parts and pieces and contributes to the longevity of the product.

Image Credits

MODO Eyewear

Project Overview

Modo Snap Hinge Eyewear has been a Silver winner in the Jewelry Design award category in the year 2021 organized by the prestigious A' Design Award & Competition. The Silver A' Design Award celebrates top-tier designs that embody excellence and innovation. This award acknowledges creations that are not only aesthetically pleasing but also highly functional, reflecting the designer's deep understanding and skill. Silver A' Design Award recipients are recognized for their contribution to raising industry standards and advancing the practice of design. Their work often incorporates original innovations and elicits a strong emotional response, making a notable impact on the improvement of everyday life.

Silver Recognition

MODO Eyewear was recognized with the coveted Silver A' Design Award in 2022, a testament to excellence of their work Modo Snap Hinge Eyewear.
